TEXTILE REINFORCED SYNTHETIC EP BELT
TEXTILE REINFORCED SYNTHETIC EP BELT : WIDTH: 1.8 M; CLASS: EP500; PLY: 5; MATERIAL:
NYLON/POLYESTER; OVERALL THICKNESS:16 MM; TEXTILE REINFORCED SYNTHETIC EP ELASTOMER POLYESTER, RUBBER QUALITY
DIN Y, TENSILE STRENGTH OF 500N/MM, TRACKING MAX 5PCT OF WIDTH MAX +/- 75MM
DIN22 102, TECHNICAL SPECIFICATION QUALITY FOR TENSILE STRENGTH 20N/MM2,
ELONGATION AT BREAK 400PCT, ABRASION 200MM3, SPECIFICATION MANUFACTURED
ACCORDING TO GENERAL PURPOSE TEXTILE REINFORCED, WITH TEXTILE PLIES,
TROUGHING IS EITHER TROUGHED , TEST CERTIFICATE TO BE SUPPLIED MUST BE
IDENTIFIABLE WITH THE SUPPLIERS NAME AND ALL TECHNICAL SPECIFICATIONS EG
FAB500/5/1800BW/6,3T/2,5B/CLASS N; VENDORS ARE RESPONSIBLE FOR ENSURING THAT
THEY ARE PERFORMING AGAINST THE CORRECT DRAWING REVISION NUMBER (IF APPLICABLE).
conveyor belt DIN T
In the HR- As per IS T1 & DIN T category, the conveyor belts are made out of special rubber compound that contains high quality SBR. They help in the transportation of material such as hot coke, clinkers & hot lime stone. Maximum temperature on the belt surface is 100 ⁰C & Maximum temperature of material handled is 125 ⁰C.
In the HR-T2 – As per IS T2 & DIN T category, special synthetic rubber compound can endure higher temperature for transportation of materials such as hot cement, sintered coke, or soda ash. The Maximum temperature on the belt surface is 125 ⁰C & Maximum temperature of material handled is 150 ⁰C.
Heat Resistant Conveyor Belts are meant to exhibit high resistance towards hot materials such as Pellets, Sinter, Cement, Powder, Chemicals and Fertilizers. These belts aren’t just heat resistant but also have a much adequate service life as their cover rubbers ensure to prevent any serious damage which high temperatures can do particularly to the conveyor belt carcass. The cover rubber of these belts are so designed to provide satisfactory tensile strength and good abrasion resistance property to ensure longer life of the belt.
DURATUF TEXTILE REINFORCED SYNTHETIC EP BELT is used for:-
- Oil treated Coal and Fertilizer
- Timber industry & sawmills
- Paper and Pulp industry
Features
Adequate Tensile Strength
The belts exhibit adequate tensile strength during their operations
Resistant to Abrasion
The belts are highly resistant towards abrasion even in oily environments
Low Maintenance
The belts need minimum maintenance & hence are very economical
Resistant to Cut and Tear
Our belts are resistant to any tearing & cuts due to concentrated oils
Anti-Slip Capability
The belts are capable of preventing themselves from slippage even in oily environment
Low Elongation
Our belts made from special polymer exhibit low elongation
