Food Grade White Rubber Conveyor Belt Heat Resistant 120 Degrees Celsius

Food Grade Rubber Conveyor Belt (1) — Food Grade Rubber Conveyor Belt

Applications:
Made of Food Grade White Rubber Conveyor Belt as the upper and lower
cover rubber,and cotton,nylon,polyester fabric
as the carcass.
Mainly used in the food industry,such as salt works,
sugar plant,pharmaceutical production,food factories,
chemical plants,etc.,suitable for various products
with strict transportation requirements.

Features:

The Food Grade White Rubber Conveyor Belt production line is
specially set up independently and meets various
food-grade certifications.
Non-toxic,tasteless,pollution-free and wear-resistant

White Rubber Food Standard Conveyor Belt for Sugar_

Specification

Strength grade	Tensile strength in wrap(Min.)	Cover recommended thickness(mm)		Belt Width(mm)
PVC	PVG
680s/Grade4	680	0.8+0.8	1.5+1.5	650~1600
800s/Grade5	800	0.8+0.8	1.5+1.5
1000s/Grade6	1000	0.8+0.8	1.5+1.5
1250s/Grade7	1250	0.8+0.8	1.5+1.5
1400s/Grade8	1400	0.8+0.8	1.5+1.5
1600s/Grade9	1600	0.8+0.8	2+2
1800s/Grade10	1800	0.8+0.8	2+2
2000s/Grade11	2000	0.8+0.8	2+2
2240s/Grade12	2240	0.8+0.8	2+2

Main Technical Data

Total Tensile Strength(N/mm)	Fabric Type	Top Cover Thickness (mm)			Bottom Cover Thickness (mm)
200-800	EP100	3	4.5	6	1.5	3
315-1250	EP150	3	4.5	6	1.5	3
400-1500	EP200	3	4.5	6	1.5	3
500-2000	EP250	3	4.5	6	1.5	3
500-2000	EP300	3	4.5	6	1.5	3
630-2500	EP400	3	4.5	6	1.5	3
Adhesion Between Layers (DIN22102) Unit: N/mm
Item	Adhesion Between Fabrics (N/mm)		Adhesion Between Fabric and Rubber (N/mm)
Item	Adhesion Between Fabrics (N/mm)		Cover≤1.5mm		Cover≥1.5mm
Max.≤	Max.≤		20		20
Ave.	Ave.		3.5		4.5
Min.≥	Min.≥		2.5		3.5
Rubber Cover Property(DIN22102)
Item			Rubber Grade
Item			W	X	Y	Z
Tensile Strength(N/mm)≥			18	25	20	15
Elongation at Break(%)≥			400	450	400	350
Abrasion≤(mm3)≥			90	120	150	250

Food Grade White Flat Smooth Rubber Conveyor Belt_y

Oil Resistance Rubber Cover Property
Item	Test Condition
Item	ASTM 471	ºC	h	L	D
1	IRM901	70±2	70±1	+20	-5
2	IRM902	70±2	70±1	+50	+5
3	IRM903	100±2	22±0.25	+50	+5

Monster belting main products include the following:steel cord conveyor belt, pipe conveyor belt,sidewall conveyor belt,heat-resistant conveyor belt,PVC/PVG mining conveyor belt,chevron conveyor belt,oil-resistant conveyor belt and fabric conveyor belt. .The company’s products have been exported to more than 40 countries and regions in Europe,America, Australia, Asia and Africa. Our factory provide customers with quality conveyor products, but also to provide customers services from selection,installation to technical training. Our factory has a well-trained after -sale service team, ready to provide services for customers.
