High Temperature Resistant Conveyor Belt:
The belt carcass of this product is EP fabric of high modulus low shrink,and high breaking tensile strength.Cover rubber of this product uses EPDM rubber or chlorobutadiene rubber that has very good high temperature resistance.It is made with extra care after mixing rubber with high temperature resistant materials,assembling and vulcanizing. The belt can bear 250 even 500 high temperature for a short time.It is suitable for use in cement,metallurgical and steel industry.
Product features:Suitable for conveying hot material like powder or clump materials at high temperature.Ideal for conveying sintered ores, cokes, soda ash, chemical fertilizer, slag and foundry.It can resist high temperature.The rubber compound used in the cover have been designed to avoid premature aging due to contact with any source of heat.Heat resistant conveyor belt can be divided into three types according to working temperature range: HRT-1 =150°C, HRT-2=180°C, HRT-3=200°C.
Products details
- Color:Black
- Edge:Mould / Cut
- Ply:2~8
- Thickness:6~50 mm
- Width:400~5000
Specifications
- High Temperature Resistant Conveyor Belt can bear 250 even 500 high temperature.
- Material :SBR / EPDM
STEEL CORD CONVEYOR BELT MULT-PLY CONVEYOR BELT
Example:2000M DIN22131 1200 ST1600 7/5 X Example:1000M DIN22102 1000 EP800/4 6/2 Y
2000M length 1000M length
DIN22131 Application standards DIN22102 Application standards
1200 Belt width in mm 1000 Belt width in mm
ST Carcass material(steel cords) EP Carcass material
1600 Belt mini breaking strength 800 Belt mini breaking strength
7 Top cover thickness in mm 6 Top cover thickness in mm
5 Bottom cover thicknessin mm 2 Bottom cover thicknessin mm
X cover grade Y cover grade
