- The warp yarn is polyester yarn which provides good tensile strength and less elongation. It allows conveyor belt to support high loads with less stretch to the conveyor belt itself.
- The weft yarn is polyamide (nylon) yarn which provides good flexibility, helps distributing the impact to provide a whole stability to fabric structure.
There are many specifications of EP fabric for making conveyor belt, please see the table below for selection guideline or contact us for more detail.
Polyester fabric tensile according to number of ply
| Fabric No. | Tensile | Total Tensile [Kg/cm] | ||||
|---|---|---|---|---|---|---|
| 2 Ply | 3 Ply | 4 Ply | 5 Ply | 6 Ply | ||
| EP 120 | 120 Kg/cm | 240 | 360 | 480 | 600 | 720 |
| EP 160 | 160 Kg/cm | 320 | 480 | 640 | 800 | 960 |
| EP 200 | 200 Kg/cm | 400 | 600 | 800 | 1000 | 1200 |
| EP 250 | 250 Kg/cm | 500 | 750 | 1000 | 1250 | 1500 |
Packaging & Delivery
— Maximum 500m per roll for rubber EP conveyor belts
— Cassette package is available for abrasion resistant conveyor belts
— One 20″ container can load 6–8 rolls DIN-Y conveyor belts
— One 40″ container can load 8–10 rolls stone crusher conveyor belts
— Inner is packed on round rubber core with 30cm diameter and 12cmx12cm square hole.
— Outer is packed with one ply water-proof PP fabric
— Customized package is available for rubber conveyor beltings
[/vc_column_text][/vc_column][/vc_row]
Polyester Fabric Belt Conveyor, usually called Carcass, is an important part of the conveyor belt. It is a heavy duty fabric that provides high tensile strength and good trough ability. It acts as the reinforcing layer giving strength and flexibility to the conveyor belt itself. We selectively choose only high quality polyester fabric to manufacture our conveyor belt. The polyester fabric and other raw materials from each source must first pass our tests before it can be put into the production line. This is to make sure that we have quality conveyor belt before passing to our customers.
EP fabric uses different type of fibre yarn in weaving.
- The warp yarn is polyester yarn which provides good tensile strength and less elongation. It allows conveyor belt to support high loads with less stretch to the conveyor belt itself.
- The weft yarn is polyamide (nylon) yarn which provides good flexibility, helps distributing the impact to provide a whole stability to fabric structure.
There are many specifications of EP fabric for making conveyor belt, please see the table below for selection guideline or contact us for more detail.
Polyester fabric tensile according to number of ply
| Fabric No. | Tensile | Total Tensile [Kg/cm] | ||||
|---|---|---|---|---|---|---|
| 2 Ply | 3 Ply | 4 Ply | 5 Ply | 6 Ply | ||
| EP 120 | 120 Kg/cm | 240 | 360 | 480 | 600 | 720 |
| EP 160 | 160 Kg/cm | 320 | 480 | 640 | 800 | 960 |
| EP 200 | 200 Kg/cm | 400 | 600 | 800 | 1000 | 1200 |
| EP 250 | 250 Kg/cm | 500 | 750 | 1000 | 1250 | 1500 |
Packaging & Delivery
— Maximum 500m per roll for rubber EP conveyor belts
— Cassette package is available for abrasion resistant conveyor belts
— One 20″ container can load 6–8 rolls DIN-Y conveyor belts
— One 40″ container can load 8–10 rolls stone crusher conveyor belts
— Inner is packed on round rubber core with 30cm diameter and 12cmx12cm square hole.
— Outer is packed with one ply water-proof PP fabric
— Customized package is available for rubber conveyor beltings
